Table of contents:

Introduction

Why take the time to read this White Paper?

This document will be of great help if you are looking for a partner who specializes in building Internet of Things solutions and provides custom IoT development services.

Our platform team shares how the IoT-based access control and management system was created. From the idea of a customer to its transition into a commercial product.

Breakdown of the solution:

  • developed a hardware platform from scratch;
  • developed firmware for the hardware platform;
  • developed mobile and web applications for B2B vocations.

If you require expert advice and support for the implementation of an IoT solution, do not hesitate to contact us at contact@2smart.com and send a description of your difficulties. We strive to help solve business-related problems.



The task presented by the customer

Customer needs

During the construction of a cottage village, an ACS was required. The client needed to organize access control for the staff and residents. At this time, ready-made solutions did not work for various reasons.

Why the existing solutions on the market did not satisfy the customer’s needs

Disadvantages of hardware platforms:

  • complex installation due to large dimensions;
  • lack of wireless connection to the network;
  • the price.

Disadvantages of software platforms:

  • the need to install on a local server. (additional costs for equipment, installation, and configuration);
  • the need to involve third-party contractors for the installation and maintenance of the system;
  • outdated, overloaded interfaces;
  • additional training is needed to use the system.

Requirements for the ACS functionality formulated together with the customer

To deal with the problem at hand, we had to develop compact controllers capable of working with typical access control equipment. Additionally, we had to develop an intuitive interface for configuring the system and providing cloud infrastructure.

The requirements were as follows:

  • design a compact controller using the technology, “Plug and Play”, to control electric locks and automation drives;
  • develop a cloud IoT access management system with the ability to operate on isolated servers;
  • develop a web interface for configuring a cloud IoT access control system;
  • provide the possibility of scaling.

Proof of Concept – assembly of a prototype that will show the general principles of ACS operation

Research of controlled devices

Before proceeding to the development of a controller prototype, it is necessary to understand what equipment such a device would control. As a result of the research, two main groups of controlled devices were identified:

  1. electric locks (electromechanical, electromagnetic, electric bolt, electric latches);
  2. electric drives for opening and lifting gates, barriers, turnstiles, and road blockers (bollards).

Their fundamental difference is that electric drives are dry contact devices that require a relay to control. Electric locks (devices with a “wet” contact), do not require a relay in the controller design.

It was discovered that in addition to the controlled devices, the ACS network controller must interact with equipment such as tag readers of various formats, and exit buttons.

Access control and management system Propuskator: a complete IoT solution

The exit button is the most straightforward device that closes an electrical circuit. As for the tag readers, it turned out that these devices interact with ACS controllers using several interfaces. The most popular being: Wiegand, Dallas Touch Memory, RS-485, OSDP, Parsec, and Clock & Data. Having studied the features of all interfaces, Wiegand 26 was chosen as the most dominant on the market. Tag readers that interact with the controller using this protocol can be found in all price categories of devices.

Choosing a Platform for Prototyping

When creating a prototype, ESP32 was chosen. One of the best platforms on the market in terms of price/performance ratio. The ESP32 microcontroller has a built-in Wi-Fi module and is compact. Not only is the ESP platform actively developed and supported by the manufacturer, but it is well documented and freely solves most of the tasks in the discussion of connected solutions.

The firmware for the prototype was developed based on the Arduino IDE. It is less functional than native ESP IDF but much easier to develop. This made it possible to speed up the testing.

Assignments that were completed using the prototype of the controller built at this stage:

  • studying the features of electric lock controlling;
  • studying the features of automation drive controlling;
  • learning the peculiarities of working with access tag readers;
  • finding the optimal power supply for the controller.

The prototype was assembled on a breadboard. Standard libraries for managing locks were installed, and then testing began.

Access control and management system Propuskator: a complete IoT solution

Implementation of the basic functions and controls of different locking equipment

The need for a relay in the circuit

At the research stage, it turned out that some devices are controlled through a relay and some directly. Initially, the relay was connected to the prototype only when needed.

However, at this stage, a setback occurred. Requiring one of two solutions:

  • the relay is included in the circuit of all controllers and is used only if necessary (technically, this circuit is suitable for all controlled devices);
  • two versions of the controller are designed. One with and one without relays.

The main advantage of the first option is the universal scheme it adopts. Advantages of the second option include: it being the simpler choice for mounting devices with a “wet” contact on controllers without relays and reducing the cost of controllers without relays.

We went with the latter. To prepare two versions of the controller for devices with different types of contact. Since the general scheme of the device is the same (only one difference in an additional element), the production of two versions is possible without costs increasing.

NO, and NC contacts

At this stage, it was discovered that the principle of the operation of different types of electric locks varies. Electromagnetic locks require a constant power supply, and the mechanism of electromechanical locks are activated by a short electrical impulse. This was taken into account in the design of the controller.

The need for an additional connection method

While testing the prototype, it turned out that one Wi-Fi connection interface is not enough and the system is not fault-tolerant. Under real circumstances, Wi-Fi may not cover the installation site and may be unstable.

Improvements to enhance resilience

It became clear that the controller must function correctly in case of loss of online connection. The device memory must contain the current access settings for processing open requests from the tag reader. An offline access event log should also be maintained. The access settings and event log should be synchronized with the data on the server when the connection is restored.

Connecting opening sensors

During the field test, we got familiar with additional equipment in the form of sensors for opening/closing gates and barriers. Their signals should prevent the gates or barriers from closing while the vehicle is passing. The requirements for their support were taken into account in further work.

The final list of requirements for an MVP based on the experience gained while creating a prototype

After confirming the attainability of the idea and identifying the key technical nuances, our specialists proceeded to the next stage, the production of a Minimum Viable Product (MVP).

The technical assignment of an MVP came with the following requirements for the controller’s functionality:

  • support for devices with “dry” (gate/barrier drive) and “wet” (electric locks) contact;
  • support for electric locks of various types;
  • support for any tag readers using the Wiegand protocol;
  • support for exit buttons;
  • support for open/close sensors for doors and gates/barriers;
  • support for a backup communication channel with a cloud server;
  • the possibility of autonomous work in case of loss of internet connection.

When writing firmware for an MVP, it is recommended to refuse the Arduino IDE development environment and use the native ESP32 – ESP IDF. What it lacks in workability, it makes up for in functionality.

MVP – the assembly of a readymade device that accomplishes the requests set by the customer

Improvement of the controller circuitry

Having started the development of the minimum viable product, our engineers kept the requirements set by the results of testing the prototype in the controller circuitry in mind:

  • two controller circuits were prepared – one with and without relays;
  • additional inputs for tag readers, exit buttons, and open/close sensors;
  • addition of a GSM Module as a backup channel for connecting to the Internet;
  • additional built-in clock to track the passage time in the absence of the Internet.

Access control and management system Propuskator: a complete IoT solution Access control and management system Propuskator: a complete IoT solution

Development of the microcontroller firmware

During development, the platform SDK was used. The firmware created with this set of tools includes the following strongpoints:

  • an admin panel for device configuration;
  • the trusty functionality of quick pairing with a mobile application;
  • the functionality of sending push notifications to the mobile application to keep up with device events;
  • the ability to update the firmware over the air.

The admin panel is a lightweight web interface integrated into the controller’s non-volatile memory.

Along with the hardware support and the ability to configure access for ACS subjects when developing the controller firmware, it was required to complete several additional tasks. Some of which demanded a bold approach.

Providing Autonomy and Synchronizing Access Rules

The offline capability has become one of the key requirements for a minimum viable product. In principle, it was decided that the current access rules for each subject will be stored in the built-in memory of the controller.

Access settings can be changed at any time, therefore actual information must be stored in the memory of each of the system controllers. The data should be updated within a few minutes and synchronization should happen automatically across the entire IoT access system.

During the development of the firmware, the functionality of regular data synchronization between the server and the controller was added. At the same time, further requirements were formed and taken into account:

  1. storing access permissions and rules in the built-in memory to ensure autonomy;
  2. seamless synchronization of access rules.

The implementation of these requirements became a key objective. Our team’s specialists have prepared a unique protocol for storing and synchronizing data with the main feature being the minimum requirements needed for the amount of built-in memory. The standard ESP32 four megabytes is enough to store access rules for thousands of users. The synchronization process has been optimized so that it’s only the data that needs updating is changing.

Synchronizing the Time Zone settings

An unapparent obstacle, encountered while preparing an MVP, was the need to synchronize the Time Zone settings. The firmware must consider the seasonal time change, otherwise, the time schedules for the ACS subjects will be faulty. The corresponding functionality has also been added to the firmware.

Production of a Zero Batch

A batch of 50 controllers has been prepared in-house. Having received a working device on a breadboard, our team prepared a printed circuit board project, and then the finished boards were ordered from China.

All the necessary components were also acquired. After receiving the batch of printed circuit boards, the controllers were then assembled by hand.

It took four months from the initial setting of the problem to the release of the MVP.

Access control and management system Propuskator: a complete IoT solution

Web and mobile applications– development of applications that solve customer needs

Functionality requirements

Following the preparation of an MVP, our team worked on the access control management software. A web application for the administrator and a mobile application for system users were developed.

The web application is used to regulate the system, which is the main center for the ACS settings. Principal requirements for its functionality include:

  • management of access rules;
  • remote control of access points;
  • add time-based access schedules for users;
  • access logging.

Web application development

One of the main features of a web application, according to the wishes of the customer, is a simple and intuitive interface. Most systems on the market were developed in the 1990s and 2000s and inherited an outdated approach to ergonomics.

While developing a web application for IoT access control administration, our team relied on modern usability standards. The result is a user-friendly web application, which the customer learned to configure on their own after a simple 15-minute demonstration.

Access control and management system Propuskator: a complete IoT solution

Development of a mobile application

The 2Smart Cloud platform provides its mobile application for remote control of IoT devices. On its basis, an application was prepared for ACS users. The main idea is that a mobile phone can replace a card or other tag. (It should be possible to open access points from the application interface.)

Using the platform’s existing tools for remote device control, we also implemented the functionality of voice command control, the ability to share access, and the ability to control via a phone call.

Access control and management system Propuskator: a complete IoT solution

First deployment and field testing

The finished controllers were configured and installed on-site while the web application was installed on a private cloud server. Field testing took place over one month. During this time, the ACS has been working without interruption, performing the assigned tasks to perfection. The customer was completely satisfied with the results.

Based on the results of field testing, the entire zero batch of 50 controllers were installed at the facilities in the village. Including the houses of residents. Additional controllers were manufactured at the request of users, whose reviews were also positive. The system continues to work and develop well.

Built-in analytics tools allow the administrator to monitor the state of the system and monitor its “health”.

Scaling to a full-fledged business

The birth of a commercial product idea

Based on the results following the field testing of a new IoT based access control system, the customer had an idea to scale the product to a commercial one. He presented our team with the task of conducting a detailed study of the access control market, especially the IoT access control market. Based on the results of such a study, a list of necessary improvements was prepared and options for positioning the product in the B2B and B2C market were proposed.

Business analysis of an idea

As part of business analysis, our team’s specialists once again studied the solutions existing on the market. If, as part of the initial task, the technical nuances and functionality of current systems were investigated, it was necessary to analyze the positioning of competitors along with their business model and pricing policy.

The goal of this procedure is to form a unique selling proposition by specifying a list of necessary technical improvements and suggesting an optimal business model.

Based on the results of the business analysis, two promising market opportunities for product promotion were identified: in the B2B, and B2C segments. Each of them was offered their own positioning and product configuration.

Proposal for the B2C segment

During the study of the B2C niche, the existing market problem was highlighted. Most solutions for the remote control of gates to a site or garage are outdated and not ideal.

Disadvantages of radio remote controls and key fobs:

  • often lost;
  • often fail, especially when exposed to rain or fluid;
  • remote controls from different manufacturers can be incompatible due to the use of different frequency ranges;
  • the encoded radio signal can be intercepted and tampered with by intruders;
  • users have to constantly hand over the remote to family members or bear the cost of making duplicates.

Disadvantages of GSM modules:

  • there is only one option for controlling the gate – a telephone call.

The solution prepared as part of the original task does not have the listed disadvantages. At the same time, it combines the advantages of both methods of remote gate control and also provides users with more functionality.

For the B2C segment, it was proposed to position the product as a universal solution for controlling gate or garage automation using a mobile phone instead of traditional control methods.

Since the controller is already performing the necessary tasks, no product reevaluation was required. The only recommendation that appeared at this stage is to place the controller in a plastic case to make the device more presentable.

For the B2C segment, it was decided to offer customers a ready-made mobile application that comes with the platform for IoT product development 2Smart Cloud.

By using the application, users have the following control methods:

  • mobile application;
  • voice commands;
  • phone call;
  • Telegram bot.

If necessary, you can quickly share access to gate control within the app.

Access control and management system Propuskator: a complete IoT solution

A finished product was offered to the B2C audience. No additional improvements and financial investments were required to enter the market.

The peculiarity of the offer for private users is that the necessity of an IoT access control system at the facility is not needed. The user installs one or more controllers and binds them to a mobile application that allows you to manage access points.

Additionally, there are restrictions set – the user can register no more than 20 physical access tokens for family members in the application.

A unique selling point is the ability to abandon remotes and GSM modules in favor of controlling the gate from a smartphone.

Target audience: owners of suburban real estate, residents of private houses, and owners of garages.

Proposal for the B2B segment

Business analysis for the B2B market included a study of the functionality of both popular, and little-known access control systems. In addition, the current market demands were studied and the customer’s experience was kept in mind when searching for an access control system.

As a result, additional functionality of the system was brought into the discussion, which will increase its competitiveness:

  1. add support for automatic reading of license plates;
  2. add the ability to bind surveillance cameras.

Unique selling points include an ACS with the possibility of self-configuration without training and the presence of a mobile application as a way to manage access points.

Target audience: cottage settlements, office centers, parking lots, businesses with a large number of access points.

Access control and management system Propuskator: a complete IoT solution

The commercial product and mass production

Approval of the improvement plan

During the stage of business analysis, the following needs of potential buyers of controllers and IoT access control systems were identified:

  • support for license plate readers;
  • support for surveillance cameras;
  • the need for a compact controller that fits in a standard socket;
  • the need for the controller to support a wired Ethernet connection with POE technology.

The decision was made to move forward with additional improvements. This will allow the introduction of a line of devices on the market to meet the listed customer needs.

It was discovered that residential complexes require support for the functionality of intercoms and elevators. The residential complex market was recognized as promising for businesses, however, finalizing the functionality of these wishes requires financial resources and time. Such improvements were included in the long-term plans.

Mass production

If a test batch of controllers was manually manufactured in the 2Smart Cloud lab, a third-party manufacturer of electronic devices had to be used for mass production. It was decided to establish production at factories in China. To speed up the process and simplify the legal side, an agreement was made to work with the manufacturer through an intermediary company registered in the PRC.

Access control and management system Propuskator: a complete IoT solution

Quality control

It is essential to personally audit the production site and internal quality control procedures. After that, it is necessary to approve the product reference sample before starting mass production.

Further quality control should include:

  • inspection by the manufacturer;
  • control on arrival from our side.

Selection of components

Since the components for the controller are also produced in the PRC, the manufacturer was entrusted with the choice of suppliers. By doing so, they must rely on the received specifications and the reference sample.

Copyright protection

Considering that even a direct prohibition in the contract for copying the design of the device is not always effective, it was decided to provide the manufacturer with only the minimum required documentation. In particular, the manufacturer did not receive the source code for the controller firmware, which would make it possible to copy the entire solution. The controllers are flashed after receiving the finished batch, after which the devices go through the final stage of quality control.

Result

The requirements put forward by the customer have been fully met when created the IoT access control ecosystem:

  • designed and manufactured compact ACS controllers with a wireless data transmission interface;
  • a web application for the administration of the IoT based access control system has been written;
  • the web application interface allows you to understand the principles of ACS administration within a few minutes;
  • users are provided with a mobile application with additional access control options;
  • system fault tolerance and seamless data synchronization are provided;
  • business analysis was carried out to scale the idea to a commercial product;
  • mass production of controllers and quality control was put into action.

Access control and management system Propuskator: a complete IoT solution

The stage of work from the moment the customer addressed us to the completion of field testing took five months. Another three months passed from the start of the business analysis to the arrival of the first batch of finished devices from China.

If you too are seeking support with IoT solutions, send a description of your interests: contact@2smart.com We will find the best solution for you.

Rate this article:

4.7 / 5. 10

( 10 votes )

Don't forget to share this post!

Let’s dive into your case

Share with us your business idea and expectations about the software or additional services.

    Thanks for contacting us!

    We will get in touch soon.

    This site is protected by Google reCAPTCHA and the following Privacy policy and Terms of use apply

    Send us a message

    This site is protected by Google reCAPTCHA and the following Privacy policy and Terms of use apply
